Maintenance of overhead lines and substations requires understanding what is being revealed during ultraviolet and infrared inspections of equipment and hardware. Do the two technologies highlight the same problem or are they rather complementary, each revealing a different aspect of that problem? Moreover, is it correct to assume that each different type of defect carries a unique ‘signature’ and therefore requires its own specific inspection technology?

This edited past contribution to INMR by Roel Stolper, a diagnostics researcher in South Africa, aimed to address these questions.


[inline_ad_1]

Utilities and research organizations worldwide have had programs to investigate and classify all the typical faults that can occur on overhead lines. For example, a past CIGRE Working Group was dedicated to understanding the behaviour of polymeric insulators under different environmental conditions.

Fig. 1: An ultraviolet and infrared recording of same phenomena show presence of corona but with no heat dissipation.
CLICK TO ENLARGE
(Left) Fig. 2: Infrared recording of capacitor bank.
(Right) Fig. 3: Bus bar clamp with corona discharges.
CLICK TO ENLARGE
(Left) Fig. 4a: Corona recording.
(Right) Fig. 4b: Infrared recording of same object.
CLICK TO ENLARGE
Acoustic inspection (Photo: Courtesy ndb Technologie).Ultraviolet corona camera inspection.
(Left) Fig. 5: Acoustic inspection (Photo: Courtesy ndb Technologie).
(Right) Fig. 6: Ultraviolet corona camera inspection.
CLICK TO ENLARGE
(Left) Fig. 7: Infrared camera inspection (Photo: Courtesy FLIR).
(Right) Fig. 8: Combined ultraviolet, infrared and visible camera inspection.
CLICK TO ENLARGE
* Based on interviews with system operators across South Africa.
CLICK TO ENLARGE

[inline_ad_2]

Current Inspection Technologies

Years of experience in line inspection have indicated that there is still no single technology that best meets every need. No diagnostic sensor will detect and locate all possible faults that can appear on an overhead line. Given this, it is correct to state that the ideal inspection tool is one that integrates different types of sensors into a single instrument. Generally speaking, inspection technology can be classified into two main groups: ultrasound radio telescopes and camera detectors. Both make use of the basic phenomenon that every defect emits radiation (i.e. energy in the electromagnetic spectrum) that can be detected and recorded by an inspection device.

Principles of ultrasound and camera detectors.
Fig. 9: Principles of ultrasound and camera detectors.
CLICK TO ENLARGE

Basic Principle of Ultrasound Detectors

A round dish focuses ultrasound radio waves onto an RF detector (microphone) that amplifies and presents any weak signal detected to the operator by means of sound produced by an earphone.

Basic Principle of Camera Detectors

Light from a source is collected by a lens, projected through a filter onto a detector that converts the light energy into electric signals. The signals are electronically manipulated into a raster image and displayed to the operator.

Principles of ultrasound and camera detectors. Multi-spectral camera system.
(Left) Fig. 10: Ultrasound disk (courtesy of CTRL Systems).
(Right) Fig. 11: Multi-spectral camera system.
CLICK TO ENLARGE
Fig. 12: UVc overlaid onto visible image showing two corona sources: dry band and discharge from a protrusion. Discharge is offset to left due to wind. Fig. 13: Thermal image showing slight heat source.
(Left) Fig. 12: UVc overlaid onto visible image showing two corona sources: dry band and discharge from protrusion. Discharge is offset to left due to wind.
(Right) Fig. 13: Thermal image showing slight heat source
CLICK TO ENLARGE
Fig. 14: Conductor termination with only corona discharges present due to protrusion.
Fig. 14: Conductor termination with only corona discharges present due to protrusion.
CLICK TO ENLARGE
Polymeric insulator with corona surface discharge and severe internally generated infrared heat.
Fig. 15: Polymeric insulator with corona surface discharge and severe internally generated infrared heat.
CLICK TO ENLARGE
Ultraviolet and infrared red recording of discharge activity at corona ring.
Fig. 16: Ultraviolet and infrared red recording of discharge activity at corona ring.
CLICK TO ENLARGE
Glass insulator string with dry band activity (left corona and right infrared recording).
Fig. 17: Glass insulator string with dry band activity (left corona; right infrared recording).
CLICK TO ENLARGE
Polymeric insulator, corona and infrared activities at dead end of insulator.
Fig. 18: Polymeric insulator, corona and infrared activities at dead end of insulator.
CLICK TO ENLARGE
Polymeric insulator, live end with corona and infrared hotspot.
Fig. 19: Polymeric insulator, live end with corona and infrared hotspot.
CLICK TO ENLARGE
Link with hot spot (middle) at contact surfaces and corona at disks (left hand).
Fig. 20: Link with hot spot (middle) at contact surfaces and corona at disks (left hand).
CLICK TO ENLARGE

The images in Figs. 12 to 20 show various ultraviolet and infrared camera recordings of electromagnetic radiation related to unique defects occurring in line components. For example, a simple structural defect (e.g. a cut in a silicone insulator housing or a damaged ceramic disc) generates corona activity due to distortion of as well as increase in electric field. Similarly, an internal defect in a composite insulator can result in leakage current along the FRP core rod, causing heat dissipation. Viewed this way, it is clear that corona and thermal cameras are essentially complementary and that neither technology is inherently superior. One can therefore also conclude that IR and UV inspection should ideally be conducted simultaneously. To demonstrate: Fig. 14 shows ultraviolet and infrared recordings of the same object. There is only corona activity present due in this case to sharp edges on the clamps. But there is no heat dissipation, suggesting that corona does not necessarily generate heat. Fig. 15, by contrast, shows a defective polymeric insulator with corona activity at the sheds as well as internal defects that produce heat.

[inline_ad_3]

Ultraviolet/Infrared Inspection with Single Device

Corona discharges are detected using an ultraviolet detector that converts ultraviolet radiation to the wavelengths that can be seen by the human eye. This same principle applies to infrared heat radiation detected by the IR uncooled micro-bolometer and subsequently converted to wavelengths in the visible spectrum.

Corona is plasma discharge whenever ambient gases are ionized. During the subsequent deionization phase, photons are emitted with emission lines related to the spectral properties of these gases. Air is made up of about 80% nitrogen, which has its dominant spectral lines in the UVA and UVB spectrum and minor lines in the UVC spectrum. The spectrum where corona radiation appears is shown in Fig. 21.

Spectral lines of corona radiation with peaks at 340 and 360nm.
Fig. 21: Spectral lines of corona radiation with peaks at 340 and 360 nm.
CLICK TO ENLARGE

In regard to heat radiation, any material emits at a wavelength that depends on body temperature, its so-called kinetic surface energy. According to Wien’s displacement law, peak wavelength, λmax, is at 2898/T, where λ is expressed in micrometers (1.10-6) and T is temperature in degrees Kelvin. Simple calculation reveals that a body at 27°C emits peak radiation at 10.55 µm such that, for example, a clamp at 100°C will have maximum radiation at 7.76 µm.

Illustration of Planck’s law.
Fig. 22: Illustration of Planck’s law.
CLICK TO ENLARGE

Calculation shows that, for any line inspection application where there are only low temperature sources, a heat detector is required to convert radiation at 8 -10 µm wavelengths into the visible spectrum. A number of heat detectors are available on the market and are classified according to spectral sensitivity as determined by material composition of the detector.

Example of response curves.
Fig. 23: Example of response curves.
CLICK TO ENLARGE

The mercury cadmium telluride (MCT) and Quantum Well (QWIP) detectors, for example, are relatively expensive since Sterling engines are required to cool them to -70° C. The micro-bolometer detector, by contrast, is used by many camera manufacturers for industrial infrared inspections. This type of detector does not need cooling and works at room temperature. It is also compact with high pixel resolution, low cost and easy availability. Fig. 25 depicts the operating principle of a multi-camera, combining all inspection technologies, i.e. visible, infrared and ultraviolet and Fig. 24 shows the spectra where it will operate.

UV and IR inspection
Fig. 24: Fig. 24: Portions of electromagnetic spectrum where multi-camera operates.
CLICK TO ENLARGE
Functional block diagram of radiometric ‘multi-camera’.
Fig. 25: Functional block diagram of radiometric ‘multi-camera’.
CLICK TO ENLARGE

[inline_ad_4]

Conclusions

Simply put, UV and IR inspection are not two alternative ways to look at the same problem. Instead, each technology records a particular defect or abnormality within the component or equipment being inspected. In general, it can be said that ultraviolet recordings indicate the presence of corona activity while infrared recordings highlight heat phenomena. Moreover, UV corona recordings have to do with surface discharges and indicate the presence of high electric field. By contrast, infrared measurements highlight presence of leakage current. The first phenomenon depends on surface condition while the second depends on an internally generated heat source.

The latest generation of multi-spectral cameras enable the power industry to simultaneously inspect electrical equipment for corona discharges and infrared hotspots. A specialized software program assists the user to record, process, store and retrieve these recordings.
